Helio-Additive API

The Helio-Additive GraphQL API offers flexibility and the ability to define precisely the data you want to fetch. The SDK's we offer utilize the API listed below in order to get started quickly, for languages we don't support the API documentation listed below can be utilized to create your own way to interact with our services.

The endpoint for requests is https://api.helioadditive.com/graphql

All requests should return a Trace-Id header, which can be used in correspondence with us to identify any problems that may have occurred.

Check out our list of Error Codes.

Examples

GraphQL requests are regular JSON requests with two keys:

{
  "query": "query Materials($pageSize: Int) { materials(pageSize: $pageSize) { id name } }",
  "variables": {"pageSize": 20}
}

The query key is a single string of graphql syntax indicating what data to fetch, and the variables key is a map of any arguments needed by the query.

GraphQL has a strong type system, as such in almost all languages there exists strong support for automatically generating code for all types & request serialization/deserialization. You simply define a set of .graphql files, generate the code, and interact with our services as if it was part of the application itself.

We have a public repository on Github with code examples listing materials & printers, uploading a G-Code and triggering a simulation for the following languages: Python, C++ & Typescript.

Notes

Requests to our API should always return a Trace-ID header, please include this trace ID in any correspondance with us so that we may further assist you with any issues you may encounter.

Queries

The query type defines GraphQL operations that retrieve data from the server.

faqs

Retrieve a list of FAQ's.

Returns: PaginatedResponse!

Arguments for faqs

Name	Description
page (Int)	The page number to retrieve
pageSize (Int)	Page size (default: 20, max: 100)

events

Retrieve a list of Events.

Returns: PaginatedResponse!

Arguments for events

Name	Description
page (Int)	Page number (1-based index)
pageSize (Int)	Page size (default: 20, max: 100)

gcodesV2

Retrieve a list of G-Codes.

Returns: PaginatedResponse!

Arguments for gcodesV2

Name	Description
page (Int)	The page number to retrieve
pageSize (Int)	Page size (default: 20, max: 100)
sortBy (GcodeField)	Field to sort the results by
sortDirection (SortDirection)	Direction to sort the results (ascending or descending).
filters ([GcodeFilter!])	List of filters to apply to the Gcode results

gcodeV2

Retrieve details of a single G-Code by its ID.

Returns: GcodeV2!

Arguments for gcodeV2

Name	Description
id (ID!)	ID of the Gcode to retrieve

gcodes

@deprecated

• Use gcodesV2 instead.
• Removed on: June 1, 2026

Retrieve a list of G-Codes.

Returns: PaginatedResponse!

Arguments for gcodes

Name	Description
page (Int)	The page number to retrieve
pageSize (Int)	Page size (default: 20, max: 100)
sortBy (GcodeField)	Field to sort the results by
sortDirection (SortDirection)	Direction to sort the results (ascending or descending).
filters ([GcodeFilter!])	List of filters to apply to the Gcode results

gcode

@deprecated

• Use gcodeV2 instead.
• Removed on: June 1, 2026

Retrieve details of a single G-Code by its ID.

Returns: Gcode!

Arguments for gcode

Name	Description
id (ID!)	ID of the Gcode to retrieve

freeTrialClaim

Retrieve the current user's free trial claim if they have one.

Returns: FreeTrialClaim

freeTrialEligibility

Check if the current user is eligible to claim a free trial.

Returns: Boolean!

featureFlagDefaults

Retrieve the default values for system feature flags.

Returns: FeatureFlagDefaults!

thermalHistories

Fetch thermal history asset data.

Returns: SimulationAsset

Arguments for thermalHistories

Name	Description
optimizationId (ID!)	(No description provided)
layer (Int!)	(No description provided)
isOptimized (Boolean!)	(No description provided)

logins

Retrieve login history for the user.

Returns: [Login!]!

personalAccessTokens

Retrieve personal access tokens for the user.

Returns: [PersonalAccessToken!]!

newsArticle

Retrieve the default simulation parameters.

Returns: NewsArticle!

Arguments for newsArticle

Name	Description
id (ID!)	(No description provided)

newsArticles

Retrieve a list of News articles.

Returns: PaginatedResponse!

Arguments for newsArticles

Name	Description
page (Int)	Page number
pageSize (Int)	Page size (default: 20, max: 100)

newsArticleFeedback

Feedback for a news article.

Returns: NewsArticleFeedback!

Arguments for newsArticleFeedback

Name	Description
newsArticleId (ID!)	(No description provided)

simulations

Retrieve a list of simulations.

Returns: PaginatedResponse!

Arguments for simulations

Name	Description
page (Int)	The page number to retrieve (1-based index).
pageSize (Int)	Page size (default: 20, max: 100)
sortBy (SimulationField)	Field to sort the results by.
sortDirection (SortDirection)	Direction to sort the results (ascending or descending).
filters ([SimulationFilter!])	List of filters to apply to the Simulation results.

optimizations

Retrieve a list of optimizations.

Returns: PaginatedResponse!

Arguments for optimizations

Name	Description
page (Int)	The page number to retrieve (1-based index).
pageSize (Int)	Page size (default: 20, max: 100)
sortBy (SimulationField)	Field to sort the results by.
sortDirection (SortDirection)	Direction to sort the results (ascending or descending).
filters ([SimulationFilter!])	List of filters to apply to the Optimization results.

printPriorityOptions

Retrieve available print priority options for optimization requests.

Returns: [PrintPriorityOption!]!

Arguments for printPriorityOptions

Name	Description
materialId (ID)	(No description provided)

defaultSimulationSettings

Retrieve the default simulation parameters.

Returns: SimulationSettings!

Arguments for defaultSimulationSettings

Name	Description
gcodeId (ID!)	The unique identifier of the G-Code for which to get default simulation settings.
roomTemperature (Float)	Ambient room temperature. Unit: $\text{K}$ Range:≥ 323
stabilizedTemperature (Float)	Stabilized air temperature. Unit: $\text{K}$ Range:≥ 323
constantPlatformTemperature (Float)	Constant platform temperature. Unit: $\text{K}$ Range:≥ 323

defaultOptimizationSettings

Retrieve the default simulation parameters.

Returns: OptimizationSettings!

Arguments for defaultOptimizationSettings

Name	Description
gcodeId (ID!)	The unique identifier of the G-Code for which to get default optimization settings.

optimization

Retrieve the default simulation parameters.

Returns: Optimization!

Arguments for optimization

Name	Description
id (ID!)	The unique identifier of the Optimization to retrieve.

simulation

Retrieve the default simulation parameters.

Returns: Simulation!

Arguments for simulation

Name	Description
id (ID!)	The unique identifier of the Simulation to retrieve.

summary

Retrieve a summary of the platform.

Returns: Summary!

getPresignedUrl

Generate a presigned URL for uploading a file.

Returns: PresignedUrl!

Arguments for getPresignedUrl

Name	Description
fileName (String!)	(No description provided)

subscriptions

Retrieve a list of available subscriptions.

Returns: PaginatedResponse!

Arguments for subscriptions

Name	Description
page (Int)	The page number to retrieve (1-based index).
pageSize (Int)	Page size (default: 20, max: 100)

subscriptionAddOns

Retrieve a list of available subscriptions.

Returns: PaginatedResponse!

Arguments for subscriptionAddOns

Name	Description
page (Int)	The page number to retrieve (1-based index).
pageSize (Int)	Page size (default: 20, max: 100)

transactionHistoriesForUser

Retrieve transaction histories for the currently authenticated user.

Returns: PaginatedResponse!

Arguments for transactionHistoriesForUser

Name	Description
page (Int)	The page number to retrieve (1-based index).
pageSize (Int)	Page size (default: 20, max: 100)

user

Retrieve the currently authenticated user.

Returns: User!

Mutations

The mutation type defines GraphQL operations that change data on the server.

createGcodeV2

Create a new G-Code.

Returns: GcodeV2!

Arguments for createGcodeV2

Name	Description
input (CreateGcodeInputV2!)	Input object containing all fields required to create a new G-Code.

deleteGcode

Delete an existing G-Code by its ID.

Returns: Boolean!

Arguments for deleteGcode

Name	Description
id (ID!)	(No description provided)

deleteOptimization

Delete an existing Optimization by its ID.

Returns: Boolean!

Arguments for deleteOptimization

Name	Description
id (ID!)	(No description provided)

claimFreeTrial

Claim a one-time 14-day free trial with unlimited optimizations.

Returns: FreeTrialClaim!

Arguments for claimFreeTrial

Name	Description
input (ClaimFreeTrialInput!)	(No description provided)

updateGcodeV2

Update an existing G-Code.

Returns: GcodeV2!

Arguments for updateGcodeV2

Name	Description
id (ID!)	The unique identifier of the G-Code to update.
input (UpdateGcodeInputV2!)	Input object containing fields to update for the specified G-Code.

createNewsArticleComment

Create a comment on a news article.

Returns: NewsArticleComment!

Arguments for createNewsArticleComment

Name	Description
newsArticleId (ID!)	(No description provided)
commentMarkdown (String!)	(No description provided)

createSimulation

@deprecated

• Use createSimulationV2 for access to temperature export controls.
• Removed on: June 1, 2026

Create a new simulation based on a G-Code.

Returns: Simulation!

Arguments for createSimulation

Name	Description
input (CreateSimulationInput!)	Input data for creating a simulation

createSimulationV2

Create a new simulation based on a G-Code (V2 - with temperature export controls).

Returns: Simulation!

Arguments for createSimulationV2

Name	Description
input (CreateSimulationInputV2!)	Input data for creating a simulation (V2)

createPaddlePortalSession

Create a Paddle portal session for managing subscriptions.

Returns: PaddlePortalSessionResponse!

createPersonalAccessToken

Create a new personal access token.

Returns: CreatePatTokenResponse!

Arguments for createPersonalAccessToken

Name	Description
name (String!)	(No description provided)
expirationDaysDelta (Int!)	(No description provided)

createOptimization

@deprecated

• Use createOptimizationV2 for access to temperature export controls.
• Removed on: June 1, 2026

Create a new optimization based on a G-code.

Returns: Optimization!

Arguments for createOptimization

Name	Description
input (CreateOptimizationInput!)	Input data for creating an optimization

createOptimizationV2

Create a new optimization based on a G-code (V2 - with temperature export controls).

Returns: Optimization!

Arguments for createOptimizationV2

Name	Description
input (CreateOptimizationInputV2!)	Input data for creating an optimization (V2)

createSuggestion

Create a new suggestion for the L-FAM platform.

Returns: Suggestion!

Arguments for createSuggestion

Name	Description
input (CreateSuggestionInput!)	(No description provided)

redeemFreeTrialCode

Redeem a free trial code for the platform.

Returns: FreeTrialCode!

Arguments for redeemFreeTrialCode

Name	Description
input (RedeemFreeTrialCodeInput!)	(No description provided)

sendOtp

Send an OTP to the user's email address.

Returns: SendOtpResponse!

Arguments for sendOtp

Name	Description
email (String!)	(No description provided)
proceed (Boolean!)	(No description provided)

stopSimulation

Stop a running simulation.

Returns: Boolean!

Arguments for stopSimulation

Name	Description
id (ID!)	(No description provided)

stopOptimization

Stop a running optimization.

Returns: Boolean!

Arguments for stopOptimization

Name	Description
id (ID!)	(No description provided)

verifyOtp

Verify the OTP sent to the user's email address.

Returns: VerifyOtpResponse!

Arguments for verifyOtp

Name	Description
email (String!)	(No description provided)
otpCode (String!)	(No description provided)

updateNewsArticleFeedback

Update feedback for a news article.

Returns: NewsArticleFeedback!

Arguments for updateNewsArticleFeedback

Name	Description
newsArticleId (ID!)	(No description provided)
input (NewsArticleFeedbackInput!)	(No description provided)

addSimulationFeedback

Add feedback for a simulation.

Returns: SimulationFeedback!

Arguments for addSimulationFeedback

Name	Description
input (SimulationFeedbackInput!)	(No description provided)

addOptimizationFeedback

Add feedback for an optimization.

Returns: OptimizationFeedback!

Arguments for addOptimizationFeedback

Name	Description
input (OptimizationFeedbackInput!)	(No description provided)

updateUser

Update the authenticated user's feature flag settings.

Returns: User!

Arguments for updateUser

Name	Description
input (UpdateUserInput!)	(No description provided)

createUser

Create a new user.

Returns: User!

Arguments for createUser

Name	Description
input (CreateUserInput!)	(No description provided)

Subscriptions

Subscriptions are useful for notifying your client in real time about changes to back-end data, such as the creation of a new object or updates to an important field.

Objects

Author

Represents a news articles comments.

Fields for Author

Name	Description
id (ID!)
name (String!)	Name of the author.
position (String!)	Position or title of the author.
avatarUrl (String)	URL of the author's avatar image.
insertedAt (DateTime!)	Timestamp when the comment was created.
updatedAt (DateTime!)	Timestamp when the comment was last updated.

Caveat

A caveat.

Fields for Caveat

Name	Description
caveatType (CaveatType!)	Caveat Type
description (String!)	Description of the caveat

CreatePatTokenResponse

Response object for creating a personal access token.

Fields for CreatePatTokenResponse

Name	Description
name (String!)
token (String!)
expiresOn (DateTime!)

Event

An event entry with details such as date, location, and status.

Fields for Event

Name	Description
id (ID!)	Unique identifier for the event.
name (String!)	Name of the event.
location (String!)	Location where the event takes place.
startDate (DateTime!)	Start date and time of the event.
endDate (DateTime!)	End date and time of the event.
link (String)	Optional URL link with more details or registration for the event.
isUpcoming (Boolean!)	Indicates if the event is upcoming based on current date.
insertedAt (DateTime!)	Timestamp when the event was created.
updatedAt (DateTime!)	Timestamp of the last update to the event.

Faq

Frequently Asked Question entry with localized question and answer content.

Fields for Faq

Name	Description
id (ID!)	Unique identifier for the FAQ entry.
question (String)	Localized question text shown to users.
answer (String)	Localized answer text shown to users.
category (FaqCategory)	Category the FAQ belongs to, such as General or Technical.
insertedAt (DateTime!)	Timestamp of when the FAQ was created.
updatedAt (DateTime!)	Timestamp of the last update to the FAQ.

FeatureFlagDefaults

Default values for system-wide feature flags.

Fields for FeatureFlagDefaults

Name	Description
enableBridgeSpeedSmoothing (Boolean!)	Smooths speed transitions over bridges for improved print quality.
enableOptimizeAboveBridge (Boolean!)	Optimizes toolpath strategy for layers printed above bridge structures.
enableFanSpeedOptimization (Boolean!)	Enable optimizing fan-speeds.
enableAlwaysUseDragonGpu (Boolean!)	Forces all simulations to use Dragon GPU acceleration (experimental).

FreeTrialClaim

Details of a user's 14-day free trial.

Fields for FreeTrialClaim

Name	Description
id (ID!)	Unique identifier for the trial claim.
claimedEmail (String!)	Email used to claim the trial.
claimedAt (DateTime!)	When the trial was claimed.
endsAt (DateTime!)	When the trial period ends.
cooldownUntil (DateTime)	When the cooldown period ends.
source (String!)	Source of the trial claim (STORE, DASHBOARD).
convertedToPaid (Boolean!)	Whether the user converted to a paid subscription.
convertedAt (DateTime)	When the user converted to paid.
isActive (Boolean!)	Whether the trial is currently active.
user (User)	User who claimed the trial.
insertedAt (DateTime!)	Timestamp when the trial was created.
updatedAt (DateTime!)	Timestamp when the trial was last updated.

FreeTrialCode

Details of free trial codes.

Fields for FreeTrialCode

Name	Description
id (ID!)	Unique identifier for the code.
code (String!)	The free trial code itself.
isUsed (Boolean!)	Indicates whether the free trial code has been used.
group (FreeTrialCodeGroup!)	The group this code belongs to.
user (User)	User who redeemed the code, if any.
insertedAt (DateTime!)	Timestamp when the free trial code was created.
updatedAt (DateTime!)	Timestamp when the free trial code was last updated.

FreeTrialCodeGroup

Details of free trial code groups.

Fields for FreeTrialCodeGroup

Name	Description
id (ID!)	Unique identifier for the code group.
subscription (HelioSubscription!)	ID of the associated subscription.
company (String!)	Company associated with the code group.
name (String!)	Name of the code group.
expirationDate (DateTime!)	Expiration date of the code group.
quantityOfCodes (Int!)	Number of codes in the group.
isExpired (Boolean!)	Whether the code group is expired.
insertedAt (DateTime!)	Timestamp when the code group was created.
updatedAt (DateTime!)	Timestamp when the code group was last updated.

Gcode

@deprecated

• Represents parsed data and metadata extracted from a G-code file. Use GcodeV2 instead.
• Removed on: June 1, 2026

Represents parsed data and metadata extracted from a G-code file. Use GcodeV2 instead.

Fields for Gcode

Name	Description
id (ID!)	Unique identifier for the G-code file.
name (String!)	Original name of the G-code file.
sizeKb (Float!)	Size of the G-code file (Unit: Kilobytes $KB$ )
height (Float!)	Maximum height reached during the print (Unit: Meters $m$ )
width (Float!)	Maximum width of the print area (Unit: Meters $m$ )
depth (Float!)	Maximum depth of the print area (Unit: Meters $m$ )
platformTemperature (GcodeCustomFloat)	Platform (bed) temperature used during the print. May be overridden or missing (Unit: Kelvin $K$ )
nozzleTemperatureMin (GcodeCustomFloat!)	Minimum nozzle temperature detected in the G-code (Unit: Kelvin $K$ )
nozzleTemperatureMax (GcodeCustomFloat!)	Maximum nozzle temperature detected in the G-code (Unit: Kelvin $K$ )
gcodeUrl (String!)	URL to the G-code file in storage, if available. May be null if not stored.
gcodeKey (String)	Key used to access the G-code file in storage. This is not a URL but a unique identifier.
roadWidthMin (GcodeCustomFloat!)	Minimum road width specified in the G-code (Unit: Meters $m$ )
roadWidthMax (GcodeCustomFloat!)	Maximum road width specified in the G-code (Unit: Meters $m$ )
layerHeightMin (GcodeCustomFloat!)	Minimum layer height specified in the G-code (Unit: Meters $m$ )
layerHeightMax (GcodeCustomFloat!)	Maximum layer height specified in the G-code (Unit: Meters $m$ )
speedMin (GcodeCustomFloat!)	Minimum print speed specified in the G-code (Unit: Meters per second $m/s$ )
speedMax (GcodeCustomFloat!)	Maximum print speed specified in the G-code (Unit: Meters per second $m/s$ )
fanSpeedMin (GcodeCustomFloat!)	Minimum fan speed used in the G-code as a percentage
fanSpeedMax (GcodeCustomFloat!)	Maximum fan speed used in the G-code as a percentage
numberOfLayers (Int!)	Total number of layers found in the G-code.
slicer (Slicer!)	Slicer software identified from the G-code metadata.
flowRatio (Float)	Optional flow ratio specified in the G-code, if available.
overrideGcodeParams (OverrideGcodeParams)	Overrides applied to G-code parameters, if any.
isSingleShell (Boolean!)	Indicates whether the print is a single-shell structure.
maxFlowRate (Float)	Maximum flow rate specified in the G-code, if available (Unit: Meters cubed per second $\frac{m^3}{s}$ )
layerHeightMode (Float)	Most frequently used layer height in the G-code, if available. (Unit: Meters $m$ )
lineWidthMode (Float)	Most frequently used line width in the G-code, if available. (Unit: Meters $m$ )
restrictions ([GcodeRestriction!]!)	List of restrictions generated during G-code parsing.
errors ([GcodeError!]!)	List of errors encountered during G-code parsing, if any.
printerId (ID!)	ID of the printer associated with this G-code.
materialId (ID!)	ID of the material used in this G-code.
insertedAt (DateTime!)	Timestamp when the G-code was first processed or uploaded.
updatedAt (DateTime!)	Timestamp of the last update to this G-code record.

GcodeCustomFloat

Represents a float value from a G-code with its override and state metadata.

Fields for GcodeCustomFloat

Name	Description
floatType (FloatType!)	Indicates the nature of the value: regular float, NaN, positive/negative infinity, etc.
isOverriden (Boolean!)	True if the value was manually overridden by the user or system.
value (Float)	The actual numeric value if valid; otherwise, null for NaN or infinite values.

GcodeErrorV2

Fields for GcodeErrorV2

Name	Description
type (GcodeError!)	The type of error that occurred.
line (Int)	The line number where the error occurred, if available.

GcodeRestrictionInfo

Fields for GcodeRestrictionInfo

Name	Description
restriction (GcodeRestriction!)	The type of restriction
description (String!)	Description of the restriction, including a link to the policy

GcodeV2

Represents parsed data and metadata extracted from a G-code file.

Fields for GcodeV2

Name	Description
id (ID!)	Unique identifier for the G-code file.
name (String!)	Original name of the G-code file.
sizeKb (Float)	Size of the G-code file in kilobytes.
height (Float)	Maximum height reached during the print. Unit: $\text{m}$
width (Float)	Maximum width of the print area. Unit: $\text{m}$
depth (Float)	Maximum depth of the print area. Unit: $\text{m}$
weight (Float)	Weight of the print. Unit: $\text{kg}$
status (GcodeStatus!)	Status of the G-code file.
progress (Float!)	Progress of the G-code file parsing.
platformTemperature (GcodeCustomFloat)	Platform (bed) temperature used during the print. May be overridden or missing. Unit: $\text{K}$
nozzleTemperatureMin (GcodeCustomFloat)	Minimum nozzle temperature detected in the G-code. Unit: $\text{K}$
nozzleTemperatureMax (GcodeCustomFloat)	Maximum nozzle temperature detected in the G-code. Unit: $\text{K}$
gcodeUrl (String!)	URL to the G-code file in storage, if available. May be null if not stored.
gcodeKey (String)	Key used to access the G-code file in storage. This is not a URL but a unique identifier.
roadWidthMin (GcodeCustomFloat)	Minimum road width specified in the G-code. Unit: $\text{m}$
roadWidthMax (GcodeCustomFloat)	Maximum road width specified in the G-code. Unit: $\text{m}$
layerHeightMin (GcodeCustomFloat)	Minimum layer height specified in the G-code. Unit: $\text{m}$
layerHeightMax (GcodeCustomFloat)	Maximum layer height specified in the G-code. Unit: $\text{m}$
speedMin (GcodeCustomFloat)	Minimum print speed specified in the G-code. Unit: $\text{m/s}$
speedMax (GcodeCustomFloat)	Maximum print speed specified in the G-code. Unit: $\text{m/s}$
fanSpeedMin (GcodeCustomFloat)	Minimum fan speed used in the G-code. Unit: $\text{\%}$ Range:0 – 100
fanSpeedMax (GcodeCustomFloat)	Maximum fan speed used in the G-code. Unit: $\text{\%}$ Range:0 – 100
numberOfLayers (Int)	Total number of layers found in the G-code.
slicer (Slicer)	Slicer software identified from the G-code metadata.
flowRatio (Float)	Optional flow ratio specified in the G-code, if available.
overrideGcodeParams (OverrideGcodeParams)	Overrides applied to G-code parameters, if any.
isSingleShell (Boolean!)	Indicates whether the print is a single-shell structure.
maxFlowRate (Float)	Maximum flow rate specified in the G-code, if available. Unit: $\frac{m^3}{s}$
layerHeightMode (Float)	Most frequently used layer height in the G-code, if available. Unit: $\text{m}$
lineWidthMode (Float)	Most frequently used line width in the G-code, if available. Unit: $\text{m}$
restrictions ([GcodeRestriction!]!)	List of restrictions generated during G-code parsing.
restrictionsV2 ([GcodeRestrictionInfo!]!)	List of restrictions generated during G-code parsing.
errors ([GcodeError!]!)	List of errors encountered during G-code parsing, if any.
errorsV2 ([GcodeErrorV2!]!)	List of errors with line numbers encountered during G-code parsing, if any.
materialId (ID!)	Material ID associated with the G-code.
printerId (ID!)	Printer ID associated with the G-code.
insertedAt (DateTime!)	Timestamp when the G-code was first processed or uploaded.
updatedAt (DateTime!)	Timestamp of the last update to this G-code record.

HelioSubscription

Details of subscriptions.

Fields for HelioSubscription

Name	Description
id (ID!)	Unique identifier for the user.
name (String!)	Name of the subscription plan.
description (String)	Description of the subscription plan.
optsPerMonth (Int!)	Number of optimization runs allowed per month under this subscription.
membershipDuration (Int)	Duration of the subscription in months.
paddlePriceId (String)	Paddle price ID for the subscription.
price (String)	Price of the subscription plan, if applicable.
features ([String!]!)	List of features included in the subscription plan.
disclaimers ([String!]!)	List of disclaimers or conditions associated with the subscription plan.
button (String)	Button text for the subscription plan.
category (String)	Category of the subscription plan.
insertedAt (DateTime!)	Timestamp when the subscription was created.
updatedAt (DateTime!)	Timestamp when the subscription was last updated.

LayerRange

Fields for LayerRange

Name	Description
fromLayer (Int!)	The starting layer number for the specified range (inclusive).
toLayer (Int!)	The ending layer number for the specified range (inclusive).

Login

Represents a user's login record.

Fields for Login

Name	Description
id (ID!)	Unique identifier of the login record.
loginType (LoginType!)	Type of login method used (e.g. username/password or Auth0).
upUsername (String)	Username used for traditional login, if applicable.
upPassword (String)	Password hash used for traditional login, if applicable.
auth0UserId (String)	Auth0 user ID if the user logged in via Auth0.
auth0Email (String)	Email associated with the Auth0 login, if applicable.
auth0EmailVerified (Boolean)	Indicates if the Auth0 email has been verified.

NewsArticle

Represents a news article.

Fields for NewsArticle

Name	Description
id (ID!)	Unique identifier for the news article.
title (String!)	The headline or title of the news article.
summary (String!)	A short summary or teaser of the article's content.
markdown (String!)	The full article content written in Markdown format.
coverUrl (String)	Optional URL to the article's cover image.
status (NewsArticleStatus!)	The current publication status of the article.
tags ([NewsArticleTag!]!)	List of tags categorizing the article.
comments ([NewsArticleComment!]!)	List of comments made on the article.
nLikes (Int!)	Number of likes the article has received.
nComments (Int!)	Number of comments on the article.
author (Author!)	The author of the article, if available.
insertedAt (DateTime!)	Timestamp when the article was created.
updatedAt (DateTime!)	Timestamp of the last article update.

NewsArticleComment

Represents a news articles comments.

Fields for NewsArticleComment

Name	Description
id (ID!)
user (User)	User associated with this login record.
commentMarkdown (String!)	Markdown content of the comment.
insertedAt (DateTime!)	Timestamp when the comment was created.
updatedAt (DateTime!)	Timestamp when the comment was last updated.

NewsArticleFeedback

Represents feedback for news articles.

Fields for NewsArticleFeedback

Name	Description
id (ID!)
user (User)	User associated with this login record.
isLike (Boolean!)	Indicates if the feedback is a like (True) or dislike (False).
isNotImportant (Boolean!)	Indicates if the feedback is marked as not important.
isNiceToHave (Boolean!)	Indicates if the feedback is marked as nice to have.
isImportant (Boolean!)	Indicates if the feedback is marked as important.
isCritical (Boolean!)	Indicates if the feedback is marked as critical.
insertedAt (DateTime!)	Timestamp when the comment was created.
updatedAt (DateTime!)	Timestamp when the comment was last updated.

Optimization

Represents an optimization simulation with detailed configuration and results.

Fields for Optimization

Name	Description
id (ID!)	Unique identifier for the optimization simulation.
spec (Int!)	Specification version or type used in the simulation.
name (String!)	Name of the optimization simulation.
index (Int!)	Index or sequence number of the simulation.
isOptimization (Boolean!)	Indicates if this is an optimization simulation.
progress (Float!)	Progress percentage of the simulation (between 0 and 100)
status (SimulationStatus!)	Current status or state of the simulation.
originalPreviewImageUrl (String)	URL for the original simulation preview image.
optimizedPreviewImageUrl (String)	URL for the optimized simulation preview image.
originalReportJsonUrl (String)	Presigned URL for the original simulation report.
optimizedReportJsonUrl (String)	Presigned URL for the optimized simulation report.
optimizedGcodeUrl (String)	Presigned URL for the optimized G-code.
optimizedGcodeWithThermalIndexesUrl (String)	Presigned URL for the optimized G-code annotated with thermal indexes.
extrusionPathsAsset (SimulationAsset)	Parquet asset with extrusion path data.
originalMeshAsset (SimulationAsset)	Parquet asset of the original public mesh.
contactsAsset (SimulationAsset)	Parquet asset with contact data.
originalCoordinateAsset (SimulationAsset)	Parquet asset with original coordinates.
optimizedMeshAsset (SimulationAsset)	Parquet asset of the optimized public mesh.
simulationSettings (SimulationSettings!)	Settings used for the simulation, including overrides for temperatures and fan speeds.
optimizationSettings (OptimizationSettings!)	Settings specific to the optimization run, including variable overrides and constraints.
optimizationReductionStrategySettings (OptimizationReductionStrategySettings!)	Settings for the reduction strategy used in the optimization run.
optimizationResidualStrategySettings (OptimizationResidualStrategySettings!)	Settings for the residual strategy used in the optimization run.
gcode (GcodeV2!)	G-code file associated with the optimization run.
optimizedThermalIndexStatistics (OptimizedThermalIndexStatistics!)	Statistics related to thermal indices in the optimization run.
originalThermalIndexStatistics (ThermalIndexStatistics!)	Statistics related to thermal indices in the original run.
optimizeOuterwall (Boolean!)	Whether to optimize the outer wall of the print.
printPriority (PrintPriority)	Print priority selection for this optimization.
enhanceSurfaceGloss (Boolean!)	Whether to enhance surface gloss for silk/glossy materials.
qualityMeanDelta (Float)	Absolute delta in mean quality between the original and optimized runs.
qualityMeanDeltaPcnt (Float)	Percentage delta in mean quality between the original and optimized runs.
qualityStdDelta (Float)	Absolute delta in standard deviation of quality between the original and optimized runs.
qualityStdDeltaPcnt (Float)	Percentage delta in standard deviation of quality between the original and optimized runs.
qualityMeanImprovement (OptimizationImprovement)	Improvement category based on absolute delta in mean quality.
qualityStdImprovement (OptimizationImprovement)	Improvement category based on absolute delta in standard deviation of quality.
originalPrintInfo (PrintInfo)	Information relating to the original print.
optimizedPrintInfo (PrintInfo)	Information relating to the optimized print.
speedFactor (Float)	How much we can improve the flow rate set
materialId (ID!)	Material ID associated with the G-code.
printerId (ID!)	Printer ID associated with the G-code.
insertedAt (DateTime!)	Timestamp when the simulation was created.
updatedAt (DateTime!)	Timestamp when the simulation was last updated.

OptimizationFeedback

Fields for OptimizationFeedback

Name	Description
id (ID!)	ID of the feedback
optimizationId (ID!)	ID of the optimization
rating (Float!)	Rating of the optimization
comment (String)	Comments about the optimization

OptimizationReductionStrategySettings

Fields for OptimizationReductionStrategySettings

Name	Description
optimizationReductionStrategy (OptimizationReductionStrategy)	Reduction strategy used in the optimization run.
optimizationReductionAutolinearDoCriticality (Boolean)	Whether to apply autolinear criticality reduction.
optimizationReductionAutolinearDoFitness (Boolean)	Whether to apply autolinear fitness-based reduction.
optimizationReductionAutolinearDoInterpolation (Boolean)	Whether to apply interpolation in autolinear reduction.
optimizationReductionAutolinearCriticalityMaxNodesDensity (Float)	Max node density for autolinear criticality.
optimizationReductionAutolinearCriticalityThreshold (Float)	Threshold value for autolinear criticality.
optimizationReductionAutolinearFitnessMaxNodesDensity (Float)	Max node density for autolinear fitness.
optimizationReductionAutolinearFitnessThreshold (Float)	Threshold value for autolinear fitness.
optimizationReductionAutolinearInterpolationLevels (Int)	Number of interpolation levels in autolinear reduction.
optimizationReductionLinearNodesLimit (Int)	Limit on number of nodes in linear reduction strategy.

OptimizationResidualStrategySettings

Fields for OptimizationResidualStrategySettings

Name	Description
optimizationResidualStrategy (OptimizationResidualStrategy)	Residual Strategy used in the optimization run.
optimizationResidualExponentialPenaltyLow (Float)	Low value of exponential penalty applied to residuals.
optimizationResidualExponentialPenaltyHigh (Float)	High value of exponential penalty applied to residuals.

OptimizationSettings

Fields for OptimizationSettings

Name	Description
minVelocity (Float!)	Minimum velocity used during optimization. Unit: $\text{m/s}$ Range:≥ 0
maxVelocity (Float!)	Maximum velocity allowed during optimization. Unit: $\text{m/s}$ Range:≥ 0
minVelocityIncrement (Float!)	Minimum velocity increment allowed. Unit: $\text{m/s}$ Range:≥ 0
minExtruderFlowRate (Float!)	Minimum extruder flow rate during optimization. Unit: $\frac{m^3}{s}$ Range:≥ 0
maxExtruderFlowRate (Float!)	Maximum extruder flow rate during optimization. Unit: $\frac{m^3}{s}$ Range:≥ 0
tolerance (Float!)	Tolerance value for convergence in optimization.
maxIterations (Int!)	Maximum number of iterations in the optimization run.
nNodes (Int!)	Number of nodes used in the optimization process.
reductionStrategySettings (ReductionStrategySettings!)	Configuration settings for the reduction strategy used during optimization.
residualStrategySettings (ResidualStrategySettings!)	Configuration settings for the residual strategy used during optimization.
layersToOptimize ([LayerRange!]!)	List of layer ranges to include in the optimization process.
optimizer (Optimizer!)	Selected optimization algorithm to use during the simulation process.
optimizeOuterwall (Boolean!)	Whether to optimize the outer wall of the print.

OptimizedThermalIndexStatistics

Fields for OptimizedThermalIndexStatistics

Name	Description
optimizedThermalIndexCount (Int)	Number of thermal index data points in the optimized simulation.
optimizedThermalIndexMean (Float)	Mean value of the optimized thermal index.
optimizedThermalIndexStd (Float)	Standard deviation of the optimized thermal index.
optimizedThermalIndexMin (Float)	Minimum value of the optimized thermal index.
optimizedThermalIndex25 (Float)	25th percentile of the optimized thermal index.
optimizedThermalIndex50 (Float)	50th percentile (median) of the optimized thermal index.
optimizedThermalIndex75 (Float)	75th percentile of the optimized thermal index.
optimizedThermalIndexMax (Float)	Maximum value of the optimized thermal index.

OverrideGcodeParams

Override values for key G-code parameters used during simulation or optimization.

Fields for OverrideGcodeParams

Name	Description
overrideConstantNozzleTemperature (Float)	Constant nozzle temperature override. Unit: $\text{K}$ Range:≥ 323
overrideConstantLayerHeight (Float)	Constant layer height override. Unit: $\text{m}$
overrideConstantRoadWidth (Float)	Constant road width override. Unit: $\text{m}$
overrideConstantPlatformTemperature (Float)	Constant platform temperature override. Unit: $\text{K}$ Range:≥ 323

PaddlePortalSessionResponse

Fields for PaddlePortalSessionResponse

Name	Description
url (String)
error (String)

PageInfo

Metadata about the pagination state.

Fields for PageInfo

Name	Description
hasPreviousPage (Boolean!)	Indicates if there is a previous page.
hasNextPage (Boolean!)	Indicates if there is a next page.

PaginatedResponse

Paginated list of objects

Fields for PaginatedResponse

Name	Description
pages (Int!)	Number of total pages available for the current query.
pageInfo (PageInfo!)	Information about pagination.
objects ([Simulation | Optimization | Event | GcodeV2 | Faq | NewsArticle | TransactionHistory | HelioSubscription | SubscriptionAddOn | Gcode!]!)	List of objects on the current page.

PersonalAccessToken

Represents a personal access token for user authentication.

Fields for PersonalAccessToken

Name	Description
name (String!)	Name or identifier for the personal access token.
expiresOn (DateTime!)	Expiration date and time of the personal access token.

PresignedUrl

Contains information for uploading a file using a presigned URL.

Fields for PresignedUrl

Name	Description
mimeType (String!)	MIME type of the file associated with the presigned URL.
url (String!)	Presigned URL allowing for direct uploads.
key (String!)	Key or identifier associated with the file in storage.

PrintInfo

Information relating to the print.

Fields for PrintInfo

Name	Description
printOutcome (PrintOutcome!)	Outcome of the print.
printOutcomeDescription (String!)	Localized outcome of the print.
temperatureDirection (TemperatureDirection!)	Temperature direction associated with the print.
temperatureDirectionDescription (String!)	Localized temperature direction associated with the print.
caveats ([Caveat!]!)	Caveats associated with the print.

PrintPriorityOption

A print priority option for dropdown selection.

Fields for PrintPriorityOption

Name	Description
value (PrintPriority!)	The enum value to send in mutations
label (String!)	Human-readable label for the option
description (String!)	Detailed description of what this priority does
isAvailable (Boolean!)	Whether this option is available for the queried material. False means it should be disabled/greyed out in the UI.

ReductionStrategySettings

Fields for ReductionStrategySettings

Name	Description
strategy (OptimizationReductionStrategy!)	The strategy used to reduce the number of nodes in the optimization process.
autolinearDoCriticality (Boolean!)	Enable automatic linear reduction based on thermal criticality.
autolinearDoFitness (Boolean!)	Enable automatic linear reduction based on fitness values.
autolinearDoInterpolation (Boolean!)	Enable interpolation during automatic linear reduction.
autolinearCriticalityMaxNodesDensity (Float!)	Maximum nodes density for criticality-based auto-linear reduction.
autolinearCriticalityThreshold (Float!)	Thermal index threshold for triggering criticality-based reduction.
autolinearFitnessMaxNodesDensity (Float!)	Maximum nodes density for fitness-based auto-linear reduction.
autolinearFitnessThreshold (Float!)	Fitness threshold for triggering fitness-based reduction.
autolinearInterpolationLevels (Int!)	Number of interpolation levels to apply in auto-linear strategy.
linearNodesLimit (Int!)	Maximum number of nodes allowed for the linear reduction strategy.

ResidualStrategySettings

Fields for ResidualStrategySettings

Name	Description
strategy (OptimizationResidualStrategy!)	The residual strategy used for optimization, such as linear or exponential.
exponentialPenaltyHigh (Float!)	Penalty applied to residuals above the target range when using exponential strategy.
exponentialPenaltyLow (Float!)	Penalty applied to residuals below the target range when using exponential strategy.

SendOtpResponse

Fields for SendOtpResponse

Name	Description
success (Boolean!)
messageId (String)
error (String)

Simulation

Represents a simulation run with associated metadata and results.

Fields for Simulation

Name	Description
id (ID!)	Unique identifier for the simulation.
name (String!)	Name or title of the simulation.
progress (Float!)	Progress percentage of the simulation (between 0 and 100)
status (SimulationStatus!)	Current status or phase of the simulation.
meshUrl (SimulationAsset)	Public-facing original mesh asset (Parquet).
gcode (GcodeV2!)	G-code used to run the simulation.
reportJsonUrl (String)	Presigned URL for downloading the original simulation report.
thermalIndexGcodeUrl (String)	Presigned URL to download thermal index G-code.
estimatedSimulationDurationSeconds (Float)	Estimated duration of the simulation in seconds.
simulationSettings (SimulationSettings!)
thermalIndexStatistics (ThermalIndexStatistics!)	Statistics related to thermal indices in the simulation.
materialId (ID!)	Material ID associated with the G-code.
printerId (ID!)	Printer ID associated with the G-code.
printInfo (PrintInfo)	Information relating to the print.
speedFactor (Float)	How much we can improve the flow rate set
suggestedFixes ([SuggestedFix!]!)	List of suggested fixes for the simulation
updatedAt (DateTime!)	Timestamp when the simulation was last updated.
insertedAt (DateTime!)	Timestamp when the simulation was created.

SimulationAsset

Fields for SimulationAsset

Name	Description
assetType (SimulationAssetType!)
url (String!)

SimulationFeedback

Fields for SimulationFeedback

Name	Description
id (ID!)	ID of the feedback
simulationId (ID!)	ID of the simulation
rating (Float!)	Rating of the simulation
comment (String)	Comments about the simulation

SimulationSettings

Fields for SimulationSettings

Name	Description
airTemperatureAboveBuildPlate (Float!)	Ambient air temperature just above the build plate. Unit: $\text{K}$ Range:≥ 323
temperatureStabilizationHeight (Float!)	Height at which temperature stabilization occurs. Unit: $\text{m}$
stabilizedAirTemperature (Float!)	The temperature maintained at the stabilization height. Unit: $\text{K}$ Range:≥ 323
constantPlatformTemperature (Float)	Optional override for the platform (bed) temperature. Unit: $\text{K}$ Range:≥ 323
constantNozzleTemperature (Float)	Optional override for the nozzle temperature. Unit: $\text{K}$ Range:≥ 323
constantFanSpeed (Float)	Optional override for fan speed as a percentage. Unit: $\text{\%}$ Range:0 – 100
temperatureHistoryDatapointsPerElement (Int)	Controls the density (resolution) of exported temperature data per element. Higher values provide more detailed temperature history.
temperatureHistoryLengthMultiplier (Int)	Controls the length (time duration) of exported temperature history data. Higher values extend the time range of recorded temperature data.

SubscriptionAddOn

Details of subscription add on.

Fields for SubscriptionAddOn

Name	Description
id (ID!)	Unique identifier for the code group.
subscriptions ([HelioSubscription!]!)	List of associated subscriptions.
name (String!)	Name of the code group.
description (String)	Description of add on
addOnOptimizationsCount (Int!)	Amount of extra optimizations
addOnPriceId (String!)	Price id from paddle
price (String)	Price of the subscription add-on, if applicable.
features ([String!]!)	List of features included in the subscription add-on.
disclaimers ([String!]!)	List of disclaimers or conditions associated with the subscription add-on.
button (String)	Button text for the subscription add-on.
category (String)	Category of the subscription plan.
insertedAt (DateTime!)	Timestamp when the add-on group was created.
updatedAt (DateTime!)	Timestamp when the add-on group was last updated.

SuggestedFix

A suggested fix.

Fields for SuggestedFix

Name	Description
orderIndex (Int)	Order index of the suggested fix
category (SuggestedFixCategory!)	Category of the suggested fix
fix (String!)	Fix to be applied
extraDetails ([String!]!)	Extra details about the suggested fix

Suggestion

Represents a suggestion for the Lfam dashboard.

Fields for Suggestion

Name	Description
id (ID!)
user (User)
content (String!)
insertedAt (DateTime!)
updatedAt (DateTime!)

Summary

Fields for Summary

Name	Description
simulationCount (Int!)
materialCount (Int!)
printerCount (Int!)

ThermalIndexStatistics

Fields for ThermalIndexStatistics

Name	Description
thermalIndexCount (Int)	Number of thermal index values in the original simulation.
thermalIndexMean (Float)	Mean of the thermal index values in the original simulation.
thermalIndexStd (Float)	Standard deviation of the original thermal index values.
thermalIndexMin (Float)	Minimum thermal index value observed.
thermalIndex25 (Float)	25th percentile of thermal index values.
thermalIndex50 (Float)	Median or 50th percentile of thermal index values.
thermalIndex75 (Float)	75th percentile of thermal index values.
thermalIndexMax (Float)	Maximum thermal index value observed.

TransactionHistory

Represents a record of a user's subscription transaction.

Fields for TransactionHistory

Name	Description
id (ID!)	Unique identifier of the transaction record.
user (User!)	The user associated with this transaction.
name (String!)	Name of the subscription or transaction item.
description (String)	Optional description of the transaction.
optsPerMonth (Int)	Number of optimizations allowed per month in this transaction.
type (TransactionType!)	Type of transaction (e.g., subscription, add-on).
subscription (HelioSubscription)	Subscription associated with this transaction, if applicable.
addOn (SubscriptionAddOn)	Add-on associated with this transaction, if applicable.
addOnOptimizations (Int)	Number of bonus optimizations granted by the add-on, if applicable.
subscriptionStartDate (DateTime)	Start date of the subscription associated with this transaction.
subscriptionEndDate (DateTime)	End date of the subscription associated with this transaction.
paddleBillingStatus (String)	Status of current transaction
insertedAt (DateTime!)	Timestamp when the transaction record was created.
updatedAt (DateTime!)	Timestamp when the transaction record was last updated.

User

Details of a user in the system.

Fields for User

Name	Description
id (ID!)	Unique identifier of the user.
email (String)	User's email address.
handle (String)	Custom user handle or username.
type (UserType!)	The user type or role in the system (e.g. Hobbyist, Academic).
avatarUrl (String)	URL to the user's avatar image.
transactionHistories ([TransactionHistory!]!)	List of the user's transaction history records.
remainingOptsThisMonth (Int)	Remaining number of optimizations allowed for the user this month.
subscriptionStartDate (DateTime)	Start date of the user's subscription, if active.
subscriptionEndDate (DateTime)	End date of the user's subscription, if active.
subscription (HelioSubscription)	Subscription details for the user, if any.
paddleBillingPeriodStart (DateTime)	Start date of the Paddle billing period.
paddleBillingPeriodEnd (DateTime)	End date of the Paddle billing period.
paddleNextBilledAt (DateTime)	Next billing date for the Paddle subscription, if applicable.
paddleBillingCycleInterval (String)	Interval for Paddle billing cycles (e.g., monthly, yearly).
paddleBillingCycleFrequency (Int)	Frequency of Paddle billing cycles (e.g., 1 for monthly, 12 for yearly).
paddleBillingStatus (String)	Status of current transaction
addOnOptimizations (Int)	Bonus optimizations
logins ([Login!]!)	List of user login records.
paddleCustomerId (String)	Paddle customer ID associated with the subscription.
lastOtpRequestedAt (DateTime)	Timestamp of the last OTP request for this user.
enableBridgeSpeedSmoothing (Boolean)	Smooths speed transitions over bridges for improved print quality.
enableOptimizeAboveBridge (Boolean)	Optimizes toolpath strategy for layers printed above bridge structures.
enableFanSpeedOptimization (Boolean)	Enable optimizing fan-speeds.
enableAlwaysUseDragonGpu (Boolean)	Forces all optimizations to use Dragon GPU acceleration (experimental).
isFreeTrialClaimed (Boolean!)	Whether user has ever claimed a free trial.
isFreeTrialActive (Boolean!)	Whether user's free trial is currently active.
freeTrialEndsAt (DateTime)	When the free trial ends (if claimed).
isFreeTrialConvertedToPaid (Boolean!)	Whether user converted trial to paid subscription.
membershipStatus (String!)	Indicates if the user has an active subscription.

VerifyOtpResponse

Fields for VerifyOtpResponse

Name	Description
success (Boolean!)
error (String)

Inputs

BooleanFilter

Fields for BooleanFilter

Name	Description
equalTo (Boolean)
notEqualTo (Boolean)

ClaimFreeTrialInput

Fields for ClaimFreeTrialInput

Name	Description
source (TrialSource!)	The source from which the trial is being claimed (STORE or DASHBOARD).

CreateGcodeInputV2

Fields for CreateGcodeInputV2

Name	Description
name (String!)	The name of the gcode.
description (String)	The description of the gcode.
materialId (ID!)	The ID of the material.
printerId (ID!)	The ID of the printer.
gcodeKey (String!)	The key of the gcode.
isSingleShell (Boolean!)	Whether the gcode is single shell.
isMultiMaterial (Boolean)	Whether the gcode is multi-material.
isMultiColor (Boolean)	Whether the gcode is multi-color.
overrideConstantNozzleTemperature (Float)	A constant nozzle temperature to override with. Unit: $\text{K}$ Range:≥ 323
overrideConstantLayerHeight (Float)	A constant layer height to override with. Unit: $\text{m}$ Range:≥ 0
overrideConstantLineWidth (Float)	A constant line width to override with. Unit: $\text{m}$ Range:≥ 0
overrideConstantPlatformTemperature (Float)	A constant platform temperature to override with. Unit: $\text{K}$ Range:≥ 323

CreateOptimizationInput

Fields for CreateOptimizationInput

Name	Description
name (String!)	User-defined name for the optimization run.
gcodeId (ID!)	Unique identifier of the G-code to optimize.
simulationSettings (SimulationSettingsInput)	Settings related to the simulation environment and initial conditions.
optimizationSettings (OptimizationSettingsInput)	Parameters and strategy configurations for running the optimization.

CreateOptimizationInputV2

Fields for CreateOptimizationInputV2

Name	Description
name (String!)	User-defined name for the optimization run.
gcodeId (ID!)	Unique identifier of the G-code to optimize.
simulationSettings (SimulationSettingsInputV2)	Settings related to the simulation environment and initial conditions.
optimizationSettings (OptimizationSettingsInput)	Parameters and strategy configurations for running the optimization.

CreateSimulationInput

Fields for CreateSimulationInput

Name	Description
name (String!)	User-defined name for the simulation.
gcodeId (ID!)	Unique identifier of the G-code to simulate.
simulationSettings (SimulationSettingsInput)	Settings related to the simulation environment and parameters.

CreateSimulationInputV2

Fields for CreateSimulationInputV2

Name	Description
name (String!)	User-defined name for the simulation.
gcodeId (ID!)	Unique identifier of the G-code to simulate.
simulationSettings (SimulationSettingsInputV2)	Settings related to the simulation environment and parameters.

CreateSuggestionInput

Fields for CreateSuggestionInput

Name	Description
content (String)	Suggestion.

CreateUserInput

Input for creating a user.

Fields for CreateUserInput

Name	Description
email (String)	Email address, if possible.

Filter

Fields for Filter

Name	Description
stringFilter (StringFilter)
floatFilter (FloatFilter)
intFilter (IntFilter)
booleanFilter (BooleanFilter)
statusFilter (SimulationStatusFilter)	This filter is only used for filtering the status of a simulation.

FloatFilter

Fields for FloatFilter

Name	Description
equalTo (Float)
notEqualTo (Float)
greaterThan (Float)
greaterThanOrEqualTo (Float)
lessThan (Float)
lessThanOrEqualTo (Float)
inList ([Float!]!)
notInList ([Float!]!)

GcodeFilter

Fields for GcodeFilter

Name	Description
field (GcodeField!)	The field to filter on, e.g., 'name', 'status'.
filter (Filter!)	The value or condition to filter the field by, e.g., 'active', 'completed'.

IntFilter

Fields for IntFilter

Name	Description
equalTo (Int)
notEqualTo (Int)
greaterThan (Int)
greaterThanOrEqualTo (Int)
lessThan (Int)
lessThanOrEqualTo (Int)
inList ([Int!]!)
notInList ([Int!]!)

LayerRangeInput

Fields for LayerRangeInput

Name	Description
fromLayer (Int!)	The starting layer number for the specified range (inclusive).
toLayer (Int!)	The ending layer number for the specified range (inclusive).

NewsArticleFeedbackInput

Fields for NewsArticleFeedbackInput

Name	Description
isLike (Boolean)	Indicates if the user liked the article. If None, it means no feedback was given.
isNotImportant (Boolean)	Indicates if the user found the article not important. If None, it means no feedback was given.
isNiceToHave (Boolean)	Indicates if the user found the article nice to have. If None, it means no feedback was given.
isImportant (Boolean)	Indicates if the user found the article important. If None, it means no feedback was given.
isCritical (Boolean)	Indicates if the user found the article critical. If None, it means no feedback was given.

OptimizationFeedbackInput

Fields for OptimizationFeedbackInput

Name	Description
optimizationId (ID!)	Unique identifier of the optimization.
rating (Float!)	Rating given by the user (0.0 - 1.0)
comment (String!)	Comment or feedback provided by the user.

OptimizationSettingsInput

Fields for OptimizationSettingsInput

Name	Description
minVelocity (Float)	Minimum print head velocity during optimization. Unit: $\text{m/s}$ Range:≥ 0
maxVelocity (Float)	Maximum print head velocity during optimization. Unit: $\text{m/s}$ Range:≥ 0
minVelocityIncrement (Float)	Minimum step size to increment velocity values during optimization. Unit: $\text{m/s}$ Range:≥ 0
minExtruderFlowRate (Float)	Minimum allowed extruder flow rate during optimization. Unit: $\text{m³/s}$ Range:≥ 0
maxExtruderFlowRate (Float)	Maximum allowed extruder flow rate during optimization. Unit: $\text{m³/s}$ Range:≥ 0
tolerance (Float)	Tolerance threshold for optimization convergence. Range:≥ 0
maxIterations (Int)	Maximum number of iterations allowed during optimization. Range:≥ 1
reductionStrategySettings (ReductionStrategySettingsInput)	Configuration settings for the reduction strategy used during optimization.
residualStrategySettings (ResidualStrategySettingsInput)	Configuration settings for the residual strategy used during optimization.
layersToOptimize ([LayerRangeInput!]!)	List of layer ranges to include in the optimization process.
optimizer (Optimizer)	Selected optimization algorithm to use during the simulation process.
optimizeOuterwall (Boolean)	@deprecated Use print_priority instead for more granular control over optimization behavior. Removed on: June 1, 2026 Flag to indicate whether to optimize the outer wall of the print.
printPriority (PrintPriority)	Print priority selection for optimization (e.g., Speed & Strength, Preserve Surface Finish, Enhance Surface Gloss).

RedeemFreeTrialCodeInput

Fields for RedeemFreeTrialCodeInput

Name	Description
code (String!)	Free trial code to redeem.

ReductionStrategySettingsInput

Fields for ReductionStrategySettingsInput

Name	Description
strategy (OptimizationReductionStrategy)	The strategy used to reduce the number of nodes in the optimization process.
autolinearDoCriticality (Boolean)	Enable automatic linear reduction based on thermal criticality.
autolinearDoFitness (Boolean)	Enable automatic linear reduction based on fitness values.
autolinearDoInterpolation (Boolean)	Enable interpolation during automatic linear reduction.
autolinearCriticalityMaxNodesDensity (Float)	Maximum nodes density for criticality-based auto-linear reduction. Unit: $\text{nodes/m}$ Range:≥ 0
autolinearCriticalityThreshold (Float)	Thermal index threshold for triggering criticality-based reduction. Range:0 – 1
autolinearFitnessMaxNodesDensity (Float)	Maximum nodes density for fitness-based auto-linear reduction. Unit: $\text{nodes/m}$ Range:≥ 0
autolinearFitnessThreshold (Float)	Fitness threshold for triggering fitness-based reduction. Range:0 – 1
autolinearInterpolationLevels (Int)	Number of interpolation levels to apply in auto-linear strategy. Range:≥ 1
linearNodesLimit (Int)	Maximum number of nodes allowed for the linear reduction strategy. Range:≥ 1

ResidualStrategySettingsInput

Fields for ResidualStrategySettingsInput

Name	Description
strategy (OptimizationResidualStrategy)	The residual strategy used for optimization, such as linear or exponential.
exponentialPenaltyHigh (Float)	Penalty applied to residuals above the target range when using exponential strategy. Range:≥ 0
exponentialPenaltyLow (Float)	Penalty applied to residuals below the target range when using exponential strategy. Range:≥ 0

SimulationFeedbackInput

Fields for SimulationFeedbackInput

Name	Description
simulationId (ID!)	Unique identifier of the simulation.
rating (Float!)	Rating given by the user (0.0 - 1.0)
comment (String!)	Comment or feedback provided by the user.

SimulationFilter

Fields for SimulationFilter

Name	Description
field (SimulationField!)	The field to filter on, e.g., 'name', 'status'.
filter (Filter!)	The value or condition to filter the field by, e.g., 'active', 'completed'.

SimulationSettingsInput

Fields for SimulationSettingsInput

Name	Description
roomTemperature (Float)	Ambient air temperature in the room. Unit: $\text{K}$ Range:≥ 323
airTemperatureAboveBuildPlate (Float)	Ambient air temperature just above the build plate. Unit: $\text{K}$ Range:≥ 323
temperatureStabilizationHeight (Float)	The height at which the air temperature around the print begins to stabilize. Unit: $\text{m}$ Range:≥ 0
stabilizedAirTemperature (Float)	The temperature maintained at the stabilization height. Unit: $\text{K}$ Range:≥ 323
constantPlatformTemperature (Float)	Optional override for the platform (bed) temperature. Unit: $\text{K}$ Range:≥ 323
constantNozzleTemperature (Float)	Optional override for the nozzle temperature. Unit: $\text{K}$ Range:≥ 323
constantFanSpeed (Float)	Optional override for fan speed as a percentage. Unit: $\text{\%}$ Range:0 – 100

SimulationSettingsInputV2

Fields for SimulationSettingsInputV2

Name	Description
roomTemperature (Float)	Ambient air temperature in the room. Unit: $\text{K}$ Range:≥ 323
airTemperatureAboveBuildPlate (Float)	Ambient air temperature just above the build plate. Unit: $\text{K}$ Range:≥ 323
temperatureStabilizationHeight (Float)	The height at which the air temperature around the print begins to stabilize. Unit: $\text{m}$ Range:≥ 0
stabilizedAirTemperature (Float)	The temperature maintained at the stabilization height. Unit: $\text{K}$ Range:≥ 323
constantPlatformTemperature (Float)	Optional override for the platform (bed) temperature. Unit: $\text{K}$ Range:≥ 323
constantNozzleTemperature (Float)	Optional override for the nozzle temperature. Unit: $\text{K}$ Range:≥ 323
constantFanSpeed (Float)	Optional override for fan speed as a percentage. Unit: $\text{\%}$ Range:0 – 100
temperatureHistoryDatapointsPerElement (Int)	Controls the density (resolution) of exported temperature data per element. Higher values provide more detailed temperature history. Range:≥ 1
temperatureHistoryLengthMultiplier (Int)	Controls the length (time duration) of exported temperature history data. Higher values extend the time range of recorded temperature data. Range:≥ 1

SimulationStatusFilter

Fields for SimulationStatusFilter

Name	Description
equalTo (SimulationStatus)
notEqualTo (SimulationStatus)

StringFilter

Fields for StringFilter

Name	Description
equalTo (String)
notEqualTo (String)
caseSensitiveContains (String)
caseInsensitiveContains (String)
caseSensitiveStartsWith (String)
caseInsensitiveStartsWith (String)
caseSensitiveEndsWith (String)
caseInsensitiveEndsWith (String)
notCaseSensitiveContains (String)
notCaseInsensitiveContains (String)
notCaseSensitiveStartsWith (String)
notCaseInsensitiveStartsWith (String)
notCaseSensitiveEndsWith (String)
notCaseInsensitiveEndsWith (String)

UpdateGcodeInputV2

Fields for UpdateGcodeInputV2

Name	Description
name (String!)	The name of the gcode.
materialId (ID!)	The ID of the material.
printerId (ID!)	The ID of the printer.
isSingleShell (Boolean!)	Whether the gcode is single shell.
overrideConstantLayerHeight (Float)	The layer height. Unit: $\text{m}$ Range:≥ 0
overrideConstantLineWidth (Float)	The line width. Unit: $\text{m}$ Range:≥ 0
overrideConstantPlatformTemperature (Float)	The platform temperature. Unit: $\text{K}$ Range:≥ 323
overrideConstantNozzleTemperature (Float)	The nozzle temperature. Unit: $\text{K}$ Range:≥ 323

UpdateUserInput

Input for updating user settings and feature flags.

Fields for UpdateUserInput

Name	Description
enableBridgeSpeedSmoothing (Boolean)	Smooths speed transitions over bridges for improved print quality.
enableOptimizeAboveBridge (Boolean)	Optimizes toolpath strategy for layers printed above bridge structures.
enableFanSpeedOptimization (Boolean)	Enable optimizing fan-speeds.
enableAlwaysUseDragonGpu (Boolean)	Forces all optimizations to use Dragon GPU acceleration (experimental).

Enums

CaveatType

Values for CaveatType

Name	Description
OVERCOOLING_WITH_SEVERE_OVERHEATED_LAYERS	Some layers show severe overheating and may fail in those regions.
OVERCOOLING_WITH_OVERHEATED_LAYERS	Some layers show overheating, which may cause local sagging or loss of detail.
OVERHEATING_WITH_SEVERE_OVERCOOLED_LAYERS	Some layers cool extremely fast, which may cause weak layer adhesion.
OVERHEATING_WITH_OVERCOOLED_LAYERS	Some layers cool faster than average, which may not achieve best strength.
OVERCOOLING_WITH_SEVERE_OVERCOOLED_LAYERS	Some layers are severely overcooled and may fail.
OVERCOOLING_WITH_OVERCOOLED_LAYERS	Some layers cool much faster than the overall average.
OVERHEATING_WITH_SEVERE_OVERHEATED_LAYERS	Some layers are severely overheated and may fail.
OVERHEATING_WITH_OVERHEATED_LAYERS	Some layers retain significantly more heat than average.
OVERCOOLED_LAYERS	Some layers are overcooled.
SEVERE_OVERCOOLED_LAYERS	Some layers are severely overcooled and may fail.
OVERHEATED_LAYERS	Some layers are overheated.
SEVERE_OVERHEATED_LAYERS	Some layers are severely overheated and may fail.

FaqCategory

Category that classifies the type of FAQ.

Values for FaqCategory

Name	Description
MATERIAL	FAQs related to materials.
SIMULATION	FAQs related to simulation processes.
GCODE	FAQs related to G-Code files and handling.

FloatType

Values for FloatType

Name	Description
NEG_INF	Represents negative infinity (−∞).
POS_INF	Represents positive infinity (+∞).
NAN	Not-a-Number — represents undefined or unrepresentable values.
VALUE	A regular float value.

GcodeError

Values for GcodeError

Name	Description
HAS_NEGATIVE_Z_COORDINATES	Negative Z-coordinates were detected in the G-code.
HAS_NO_COMMANDS	No valid command was detected in the G-code.
HAS_UNCERTAIN_ENCODING	Uncertain encoding was detected in the G-code.
HAS_ZERO_SPEED	Zero speed was detected in the G-code.
HAS_MULTI_MATERIAL_PRINTING	Multi-material or multi-color printing commands were detected in the G-code.
COMMAND_FORMAT_ERROR	Command format error was detected in the G-code.
COMMENT_FORMAT_ERROR	Comment format error was detected in the G-code.
VALUE_ERROR	A value error was detected in the G-code during parsing.
LAYER_HEIGHT_NOT_FOUND	Layer height was not detected in the G-code.
LINE_WIDTH_NOT_FOUND	Line width was not detected in the G-code.
NOZZLE_TEMPERATURE_NOT_FOUND	Nozzle temperature was not detected in the G-code.
PLATFORM_TEMPERATURE_NOT_FOUND	Platform temperature was not detected in the G-code.
INTERNAL_ERROR	Something unexpected happened during parsing, this should be reported to us.
MULTI_MATERIAL_UNABLE_TO_DETECT_MATERIAL_SWITCH	Unable to properly detect material switch in the multi-material G-code.

GcodeField

Values for GcodeField

Name	Description
NAME
DESCRIPTION
SIZE_KB
HEIGHT
WIDTH
DEPTH
ROAD_WIDTH
LAYER_HEIGHT
PLATFORM_TEMP
FLOW_RATIO
NOZZLE_TEMP
INFILL_SPEED
NUMBER_OF_LAYERS

GcodeRestriction

Values for GcodeRestriction

Name	Description
SIZE_TOO_LARGE
WEIGHT_TOO_HEAVY

GcodeStatus

Values for GcodeStatus

Name	Description
INITIALIZING	Initializing a parser to parse a G-Code.
PARSING	Parsing the G-Code.
READY	Finished parsing the G-Code and it is now ready to be used.
ERROR	Errors occurred preventing this G-Code to be used. See GcodeError for more details.
RESTRICTED	The G-Code contains no specific errors, but is restricted from simulations & optimizations due to size or weight.

LoginType

Values for LoginType

Name	Description
USERNAME_PASSWORD	User logs in using a username and password combination.
AUTH_0	User logs in using Auth0.

NewsArticleStatus

Status of a news article.

Values for NewsArticleStatus

Name	Description
UNDER_CONSIDERATION	The article is currently being reviewed or considered for publication.
IN_DEVELOPMENT	The article is actively being written or developed.
RECENTLY_RELEASED	The article has been published recently.

NewsArticleTag

Tags associated with a news article.

Values for NewsArticleTag

Name	Description
PRINTER	Articles related to printers.
MATERIAL	Articles related to materials used in 3D printing.
GCODE	Articles related to G-code, the language used to control 3D printers.
SIMULATION	Articles related to simulation processes in 3D printing.
COMPANY	Articles related to companies in the 3D printing industry.
UPDATES	Articles that provide updates on various topics.
MISC	Miscellaneous articles that do not fit into other categories.

OptimizationImprovement

Values for OptimizationImprovement

Name	Description
LOW	Simulation improved.
MEDIUM	Simulation improved moderately.
HIGH	Simulation improved significantly.

OptimizationReductionStrategy

Values for OptimizationReductionStrategy

Name	Description
AUTOLINEAR	Automatically adjusts nodes and strategies based on conditions.
LINEAR	Applies a fixed linear reduction of nodes.
NO_STRATEGY	No reduction strategy is applied.

OptimizationResidualStrategy

Values for OptimizationResidualStrategy

Name	Description
LINEAR	Applies a fixed linear reduction of nodes.
EXPONENTIAL	Applies an exponential reduction of nodes.

Optimizer

Values for Optimizer

Name	Description
FULL	Full Optimizer
HYBRID	Hybrid Optimizer

PrintOutcome

Values for PrintOutcome

Name	Description
WILL_PRINT	Will Print
MAY_PRINT	May print with issues
LIKELY_FAIL	Will likely fail to print

PrintPriority

Print priority options for optimization requests.

Values for PrintPriority

Name	Description
SPEED_AND_STRENGTH	Optimizes outer walls for improved performance. (Formerly 'Optimize Outer Walls: Yes')
PRESERVE_SURFACE_FINISH	Maintains your original outer wall speed settings. (Formerly 'Optimize Outer Walls: No')
ENHANCE_SURFACE_GLOSS	Optimizes for silk/glossy materials with enhanced surface finish.

SimulationAssetType

Defines the type or format of a simulation asset.

Values for SimulationAssetType

Name	Description
PARQUET	Asset is in Apache Parquet format.
JSON	Asset is in JSON format.

SimulationField

Defines the simulation fields

Values for SimulationField

Name	Description
NAME	Name of the simulation.
STATUS	Current status of the simulation.
IS_BAAM	Indicates if the simulation is a LFAM (Large Format Additive Manufacturing) simulation.
IS_OPTIMIZATION	Indicates if the simulation is an optimization simulation.
PROGRESS	Current progress of the simulation, represented as a percentage.
PRINTABILITY	Printability score of the simulation, indicating how suitable the design is for printing.
BONDING_RATE_MEAN	Mean bonding rate of the simulation, indicating the average adhesion strength between layers.
BONDING_RATE_STD	Standard deviation of the bonding rate, indicating variability in adhesion strength.
BONDING_RATE_MIN	Minimum bonding rate observed in the simulation, indicating the weakest adhesion strength.
BONDING_RATE_MAX	Maximum bonding rate observed in the simulation, indicating the strongest adhesion strength.
EQUIVALENT_TIME_MEAN	Mean equivalent time for the simulation, representing the average time taken for the process.
EQUIVALENT_TIME_STD	Standard deviation of the equivalent time, indicating variability in process duration.
EQUIVALENT_TIME_MIN	Minimum equivalent time observed in the simulation, indicating the shortest process duration.
EQUIVALENT_TIME_MAX	Maximum equivalent time observed in the simulation, indicating the longest process duration.
THERMAL_INDEX_MEAN	Mean thermal index of the simulation, indicating the average thermal performance.
THERMAL_INDEX_STD	Standard deviation of the thermal index, indicating variability in thermal performance.
THERMAL_INDEX_MIN	Minimum thermal index observed in the simulation, indicating the lowest thermal performance.
THERMAL_INDEX_MAX	Maximum thermal index observed in the simulation, indicating the highest thermal performance.

SimulationStatus

Represents the current lifecycle status of a simulation.

Values for SimulationStatus

Name	Description
PENDING	Simulation is queued and waiting to start.
INITIALIZING	Simulation is preparing resources and initializing.
SIMULATING	Simulation is currently running.
ARCHIVING	Simulation has completed and is archiving results.
FINISHED	Simulation completed successfully.
FAILED	Simulation encountered an error and failed.
STOPPED	Simulation was manually stopped before completion.

Slicer

Values for Slicer

Name	Description
SIMPLIFY3D
IDEAMAKER
CURA
BAMBU_LABS
SUPERSLICER
SLIC3R
FUSION360
BAAM
MW
CEAD_BAAM
KRAUSS_MAFFEI
PIOCREATE
KUYING
CEAD
AI_BUILD
AI_BUILD_GCODE
AI_BUILD_SRC
ADAONE
PRUSA_SLICER
SIGNIFY
ORCA_SLICER
CARACOL
UNKNOWN
CREALITY_PRINT

SortDirection

sort direction for paginated queries.

Values for SortDirection

Name	Description
ASCENDING
DESCENDING

SuggestedFixCategory

The category for a suggested fix.

Values for SuggestedFixCategory

Name	Description
QUICK	Quick fix
ADVANCED	Advanced fix
EXPERT	Expert fix

TemperatureDirection

Values for TemperatureDirection

Name	Description
NONE	Temperature is within range
OVERCOOLING	Temperature is too low
OVERHEATING	Temperature is too high

TransactionType

Values for TransactionType

Name	Description
SUBSCRIPTION
ADD_ON
PAYMENT_FAILED

TrialSource

Source of the free trial claim.

Values for TrialSource

Name	Description
STORE	Trial claimed from the store/pricing page.
DASHBOARD	Trial claimed from the user dashboard.

UserType

Values for UserType

Name	Description
HOBBYIST	User is a hobbyist, often engaging in 3D printing for personal projects or fun.
ACADEMIC	User is affiliated with an academic institution, likely using 3D printing for research or educational purposes.
PROFESSIONAL	User uses 3D printing in a professional context, often for commercial purposes or in a business setting.
INDUSTRIAL	User is part of an industrial setting, using 3D printing for large scale or high-end applications.

Scalars

ID

Used for ID's and can be treated as a String

String

A string datatype

Int

An integer data type

Float

A floating-point data type

Boolean

A boolean data type

DateTime
