Code Generation with GraphQL

One of the major benefits of using our GraphQL API is that you should not need to write your own code to interact with it. You should only need to write .graphql files that reflect exactly what data you want to query or mutate, run the GraphQL code generation tool in your language, then use as if our service was part of your own application, complete with strongly typed functions, enums, interfaces/structs/classes, etc…

The following provides examples in popular languages of how to do this.

TypeScript

TypeScript Setup

The following example uses Bun as the bundler & runtime environment.

1. Start a new project and install dependencies

   #!/bin/bash
   mkdir example && cd example
   bun init

   # Runtime dependencies
   bun add @apollo/client

   # Development dependencies
   bun add @graphql-codegen/cli @graphql-codegen/near-operation-file-preset --dev

2. Setup codegen configuration

   We will create a codegen file with some configuration for how we want to generate the code.

   ./codegen.ts

   import type { CodegenConfig } from "@graphql-codegen/cli";

   const config: CodegenConfig = {
     overwrite: true,
     schema: "https://api.helioadditive.com/graphql"
     documents: "./**/*.graphql",
     generates: {
       "types.generated.ts": {
         plugins: ["typescript"],
         config: {
           useInterface: true,
           useTypeImports: false,
           declarationKind: {
             input: "interface",
           },
         },
       },
       ".": {
         preset: "near-operation-file",
         presetConfig: {
           extension: ".generated.ts",
           baseTypesPath: "types.generated.ts",
         },
         plugins: ["typescript-operations", "typed-document-node"],
         config: {
           useTypeImports: false,
           declarationKind: {
             input: "interface",
           },
         },
       },
     },
   };

   export default config;

3. Create a graphql file to query data

   You choose what data you want to fetch

   ./queries/Materials.graphql

   query ListMaterials($page: Int, $pageSize: Int, $filters: [MaterialFilter!]) {
     materials(page: $page, pageSize: $pageSize, filters: $filters) {
       pages
       pageInfo {
         hasPreviousPage
         hasNextPage
       }
       objects {
         ... on Material {
           id
           name
           brand {
             id
             name
           }
         }
       }
     }
   }

4. Autogenerate files

   Add a new script to your package.json to run the codegen tool.

   ./package.json

   {
     "name": "example",
     "version": "0.1.0",
     "scripts": {
       ...
      "codegen": "graphql-codegen --config codegen.ts"
     },

   And then run it:

   bun run codegen

5. Create a client

   Apollo provides a lot of tooling for GraphQL in TypeScript. We simply leverage their client & configure it as needed.

   ./ApolloClient.ts

   import { ApolloClient, InMemoryCache, HttpLink } from "@apollo/client";

   export const apolloClient = new ApolloClient({
     uri: "https://api.helioadditive.com/graphql",
     cache: new InMemoryCache(),
     link: new HttpLink({
       uri: "https://api.helioadditive.com/graphql",
       headers: {
         "Content-Type": "application/json",
         Authorization: "Bearer <pat-token>"  // The users PAT token should be dynamically inserted here
       },
       credentials: "include",
       fetchOptions: { cache: "no-store" },
     }),
   });

6. Utilize the generated code

   In any application code, you now need only import the client and pass the automatic generated Document from a .generated.ts document.

   ./main.ts

   import { apolloClient } from "@/ApolloClient";
   import { MaterialsDocument } from "./queries/Materials.generated";

   // Construct a query
   const query = await apolloClient.query({
      query: MaterialsDocument,
      variables: {
        pageSize: 20,
        page: 1
      },
      fetchPolicy: "no-cache",
    });

    // The following is all strongly typed
    for (const material of materials.data.materials.objects) {
      console.log(`Material ID: ${material.id}, Name: ${material.name}`);
    }

Python

Python Setup

The following example uses uv as the package manager and ariadne-codegen for code generation.

1. Start a new project and install dependencies

   uv is a modern Python package manager:

   #!/bin/bash
   mkdir example && cd example
   uv init
   uv add ariadne-codegen  # GraphQL codegen tool

2. Setup codegen configuration

   Update the pyproject.toml file to specify settings for autogenerated code.

   ./pyproject.toml

   [project]
   name = "example"
   version = "0.1.0"
   description = "Add your description here"
   readme = "README.md"
   requires-python = ">=3.13"
   dependencies = [
       "ariadne-codegen>=0.14.0",
   ]

    [tool.ariadne-codegen]
    target_package_path = "./client"
    queries_path = "./queries"
    remote_schema_url = "https://api.helioadditive.com/graphql"
    target_package_name = "graphql_client"
    async_client = true
    include_comments = "stable"
    convert_to_snake_case = true
    include_all_inputs = true
    include_all_emums = true

3. Create a graphql file to query data

   You choose what data you want to receive

   ./queries/Materials.graphql

   query ListMaterials($page: Int, $pageSize: Int, $filters: [MaterialFilter!]) {
     materials(page: $page, pageSize: $pageSize, filters: $filters) {
       pages
       pageInfo {
         hasPreviousPage
         hasNextPage
       }
       objects {
         ... on Material {
           id
           name
           brand {
             id
             name
           }
         }
       }
     }
   }

4. Autogenerate the code

   uv run ariadne-codegen --config pyproject.toml

   All generated code should now be generated in the ./client directory

5. Update the main.py to use the generated code

   Notice that there is no logic to handle the requests, that logic is already autogeneratd and baked into functions like materials

   ./main.py

   import asyncio
   import httpx
   from client.client import client

   headers = {"Authorization": "Bearer <helio_pat>"}
   graphql_client = Client(
       url="https://api.helioadditive.com/graphql",
       headers=headers,
       http_client=httpx.AsyncClient(headers=headers, timeout=60)
   )

   async def main():
       materials = await graphql_client.materials(page_size=20)
       for material in materials.objects:
           # The `material` object is fully type inferred
           material_id = material.id
           material_name = material.name

   if __name__ == "__main__":
       asyncio.run(main())

6. Next steps

   You can now add any .graphql files you need into the queries directory, re-run the codegen tool, and start using it directly in the code.

Rust

Rust Setup

The following example uses graphql-client for compile-time code generation.

1. Start a new project and install dependencies

   Create a new Rust project and add dependencies:

   #!/bin/bash
   cargo new example && cd example

   Add dependencies to Cargo.toml:

   ./Cargo.toml

   [package]
   name = "example"
   version = "0.1.0"
   edition = "2021"

   [dependencies]
   graphql_client = "0.14"
   reqwest = { version = "0.12", features = ["json"] }
   serde = { version = "1.0", features = ["derive"] }
   serde_json = "1.0"
   tokio = { version = "1", features = ["full"] }

2. Download the GraphQL schema

   curl https://helioadditive-public.s3.ap-east-1.amazonaws.com/docs/schema.graphqls -o schema.graphqls

3. Create a graphql file to query data

   Create a queries directory and add your query:

   ./queries/materials.graphql

   query ListMaterials($page: Int, $pageSize: Int, $filters: [MaterialFilter!]) {
     materials(page: $page, pageSize: $pageSize, filters: $filters) {
       pages
       pageInfo {
         hasPreviousPage
         hasNextPage
       }
       objects {
         ... on Material {
           id
           name
           brand {
             id
             name
           }
         }
       }
     }
   }

4. Use the graphql_client macro

   The graphql_client crate uses Rust’s procedural macros to generate code at compile time rather than generated actual files:

   ./src/main.rs

   use graphql_client::{GraphQLQuery, Response};
   use reqwest::header::{AUTHORIZATION, CONTENT_TYPE};

   #[derive(GraphQLQuery)]
   #[graphql(
       schema_path = "schema.graphqls",
       query_path = "queries/materials.graphql",
       response_derives = "Debug"
   )]
   struct ListMaterials;

   #[tokio::main]
   async fn main() -> Result<(), Box<dyn std::error::Error>> {
       let pat_token = std::env::var("PAT").expect("PAT environment variable must be set");

       let client = reqwest::Client::new();
       let variables = list_materials::Variables {
           page: Some(1),
           page_size: Some(5),
           filters: None,
       };

       let response = client
           .post("https://api.helioadditive.com/graphql")
           .header(CONTENT_TYPE, "application/json")
           .header(AUTHORIZATION, format!("Bearer {}", pat_token))
           .json(&ListMaterials::build_query(variables))
           .send()
           .await?;

       let body: Response<list_materials::ResponseData> = response.json().await?;

       if let Some(errors) = body.errors {
           return Err(format!("GraphQL errors: {:?}", errors).into());
       }

       let data = body.data.expect("No data returned");
       println!("Fetched {} pages of materials", data.materials.pages);
       println!("Has next page: {}", data.materials.page_info.has_next_page);

       for material in data.materials.objects {
           println!("\nMaterial: {} (ID: {})", material.name, material.id);
           if let Some(brand) = &material.brand {
               println!("  Brand: {} (ID: {})", brand.name, brand.id);
           }
       }

       Ok(())
   }

5. Run the application

   cargo run

C++

Caution

This example uses features from C++20, while generally not a problem it is noted that alot of existing C++ slicers still use C++17. This requirment is due to Microsofts cppgraphqlgen library leveraging Coroutines for quite a few versions. We will provide a C++17 example when we have time.

C++ Setup

1. Start a new project and install dependencies

   Create project Setup vcpkg in the example

   #!/bin/bash
   mkdir example && cd example

2. Setup vcpkg & install dependencies

   Create the vcpkg.json file:

   ./vcpkg.json

   {
     "name": "example",
     "version-string": "0.0.1",
     "builtin-baseline": "095a29ce59608465032c3747307dd0009b3e089c",
     "dependencies": [
       {
         "name": "pegtl",
         "version>=": "3.2.8"
       },
       {
         "name": "cppgraphqlgen",
         "version>=": "4.5.7",
         "features": ["clientgen", "rapidjson"]
       },
       {
         "name": "boost-json",
         "version>=": "1.88.0"
       },
       {
         "name": "cpr",
         "version>=": "1.11.2"
       }
     ]
   }

   And then setup / install:

   git submodule add https://github.com/microsoft/vcpkg
   ./vcpkg/bootstrap-vcpkg.sh
   ./vcpkg/vcpkg install

3. Create a graphql file to query data

   You choose what data you want to fetch

   ./queries/Materials.graphql

   query ListMaterials($page: Int, $pageSize: Int, $filters: [MaterialFilter!]) {
     materials(page: $page, pageSize: $pageSize, filters: $filters) {
       pages
       pageInfo {
         hasPreviousPage
         hasNextPage
       }
       objects {
         ... on Material {
           id
           name
           brand {
             id
             name
           }
         }
       }
     }
   }

4. Autogenerate the code

   clientgen allows us to autogenerated all of the functions, structs and enums needed to handle our query files. This means we don’t need to write any manual requests with possible incorrect types, just call the function as if it were part of the library itself.

   mkdir -p ./generated/src
   mkdir -p ./generated/include
   curl https://api.helioadditive.com/graphql/scehma -o schema.graphqls
   ./vcpkg/packages/cppgraphqlgen_arm64-osx/tools/cppgraphqlgen/clientgen \
       --schema ./schema.graphqls \
       --request queries/Materials.graphql \
       --namespace HelioAdditive \
       --prefix Materials \
       --source-dir ./generated/src \
       --header-dir ./generated/include

5. Create the main.cpp app entrypoint

   All of the structs, enums and functions to handle all types to/from our API are already autogenerated including the serialization logic. This means you can now write interact with our API with 100% type confidence.

   ./src/main.cpp

   #include <iostream>
   #include <string>

   #include "MaterialsClient.h"
   #include "graphqlservice/GraphQLResponse.h"
   #include "graphqlservice/JSONResponse.h"

   namespace Materials = graphql::client::query::Materials;

   int main() {
       const std::string query = Materials::GetRequestText();
       graphql::response::Value variables = Materials::serializeVariables(Materials::Variables{.pageSize = 20, .page = 1});
       auto parsed_response = Materials::parseResponse(sendHttpRequest(query, variables));

       for (const auto &material : parsed_response.materials.objects) {
           std::cout << "Material ID: " << material.id.c_str() << ", Name: " << material.name << '\n';
       }

       return 0;
   }

   NOTE: C++ autogenerated GraphQL code does not include logic to handle the HTTP requests like in other languages, as such an example function of how to handle the HTTP requests is shown below with cpr, but one could easily use boost or libcurl based on what is used in your project:

   #include <cpr/cpr.h>
   #include <boost/json.hpp>

   graphql::response::Value sendHttpRequest(const std::string &query, graphql::response::Value &variables) {
       std::string body = boost::json::serialize(boost::json::object{
           {"query", query},
           {"variables", boost::json::parse(graphql::response::toJSON(std::move(variables))).as_object()}
       });
       return graphql::response::parseJSON(boost::json::serialize(boost::json::parse(
           cpr::Post(
               cpr::Url{"https://api.helioadditive.com/graphql"},
               cpr::Header{{"Content-Type", "application/json"}, {"Authorization", "Bearer <pat_token>"}},
               cpr::Body{body}
           ).text
       ).as_object()["data"].as_object()));
   }

6. Build

   C++ is an advanced language and every build system is different. For below example shows how one could use CMake to build:

   cmake_minimum_required(VERSION 3.14)
   project(ExampleApp)
   set(CMAKE_CXX_STANDARD 20)
   set(CMAKE_CXX_FLAGS "-std=c++20 -O3 ")

   include_directories(${VCPKG_DIR}/include)
   link_directories(${VCPKG_DIR}/lib)

   FIND_PACKAGE(CURL)
   find_package(Boost REQUIRED COMPONENTS json)
   find_package(cppgraphqlgen 4.5.7 CONFIG REQUIRED)
   find_package(cpr 1.11.1 REQUIRED)

   include_directories(generated/include)
   file(GLOB_RECURSE GENERATED_SRC "generated/src/*.cpp")
   file(GLOB_RECURSE GENERATED_HEADERS "generated/include/*.h")

   add_executable(ExampleApp src/main.cpp ${GENERATED_SRC})
   include_directories({CURL_INCLUDE_DIRS})
   target_link_libraries(ExampleApp
       PRIVATE
       cppgraphqlgen::graphqlservice
       cppgraphqlgen::graphqlclient
       cppgraphqlgen::graphqlresponse
       cppgraphqlgen::graphqlpeg
       cppgraphqlgen::graphqlcoro
       cppgraphqlgen::graphqljson
       taocpp::pegtl
       cpr::cpr
       Boost::json
   )
   target_include_directories(ExampleApp
       PUBLIC
       $<BUILD_INTERFACE:${CMAKE_CURRENT_SOURCE_DIR}/generated>
       $<INSTALL_INTERFACE:generated/include>
       PRIVATE
       ${VCPKG_DIR}/include
   )
